VALUE Field Plug Cat.6A (Class EA), STP
- Item number
- 26.99.0373-50
- Part number
- 26.99.0373
- EAN
- 7630049690097
- Brand
- VALUE
- Weight
- 20.3 g
Fast and easy tool-free installable shielded RJ45 connector Cat.6A / Class EA performance according to ISO/IEC11801 and IEC60603-7 Compact cable manager for round Solid cable AWG 23-26(1/0.41-1/0.575mm) and stranded…
This product is not sold online — send an enquiry and we will reply with price and lead time.
Request a quoteDescription
- Fast and easy tool-free installable shielded RJ45 connector
- Cat.6A / Class EA performance according to ISO/IEC11801 and IEC60603-7
- Compact cable manager for round Solid cable AWG 23-26(1/0.41-1/0.575mm) and stranded cable AWG 24-26(7/0.16-7/0.20mm)
- For cable with outer diameter OD: 6.0 - 9.0mm
- Pair management according to TIA 568B and TIA 568A colour codes
- Robust zinc die-cast housing
- Strain relief with cable tie and black transparent dust cup and boot
- Color: silver
Specifications
Product
- Manufacturer
- VALUE
- Product group
- Connection technology TP
- Product type
- Connectors RJ-45
- Colour
- silver
- Shield type
- Screened
- Transfer quality
- Cat6A / Class EA
- Quantity of ports
- 1
- Side 1 Connector Type
- RJ-45
- Side 1 Connector Gender
- Male
- Shield contacts
- ja
- separate strain relief
- yes
- Height
- 15.3 mm
- Width
- 14.1 mm
- Depth
- 67.8 mm
- Weight
- 20.3 g
Packaging
- Height of packaging (single piece)
- 20 mm
- Width of packaging (single piece)
- 20 mm
- Depth of packaging (single piece)
- 20 mm
- Package weight (single piece)
- 0.02 kg
