VALUE Connection Module Cat.6A (Class EA), STP
- Item number
- 26.99.0380-50
- Part number
- 26.99.0380
- EAN
- 7630049690783
- Brand
- VALUE
- Weight
- 33 g
CAT. 6a STP connection module for route extension using two network / installation cables
Description
CAT. 6a STP connection module for route extension using two network / installation cables
- The VALUE Junction module is used to repair or extend shielded Cat. 6A cables
- With this module all 4 or 8 wired installation cables with AWG24 and with an outside diameter from 6.2mm can be installed
- Equipped with the modern LSA connection technology, all cables in accordance with EIA/TIA 568A or 568B can be easily installed
- With the use of the STP type junction box, it's safe against electrical and magnetical interferences
- For Solid wire only
Specifications
Product
- Manufacturer
- VALUE
- Product group
- Connection technology TP
- Product type
- Network junction box
- Colour
- silver
- Shield type
- Screened
- Transfer quality
- Cat6A / Class EA
- Quantity of ports
- 1
- Assignment
- EIA/TIA 568B
- Shield contacts
- yes
- Connection direction
- Straight
- Dimensions (HxWxD)
- 26 x 32 x 60 mm
- Height
- 26 mm
- Width
- 32 mm
- Depth
- 60 mm
- Weight
- 33 g
Packaging
- Height of packaging (single piece)
- 20 mm
- Width of packaging (single piece)
- 20 mm
- Depth of packaging (single piece)
- 20 mm
- Package weight (single piece)
- 0.035 kg
